JS-LYT 24V RGB, CCT & Smart LED Strips – Tunable White, Multi-Colour & IC Running (5m/10m Roll, 2-Year Warranty)
Couldn't load pickup availability
JS-LYT 24V RGB, CCT & Smart LED Strips – 2-Year Warranty
Colour-changing and tunable-white 24V LED strips – from simple 3CCT tunable-white strips through full RGB, RGB+CCT multi-in-1, and IC-driven running-effect strips. 6 wattages from 12W/m to 24W/m across 2835, 3535 and 5050 chip strips, supplied in 5m or 10m rolls, backed by a 2-year manufacturer warranty. Each strip needs a matching controller (3CCT, RGB, RGBW or IC) – ask us if you're not sure which one you need.
Product Range
1. 3CCT Tunable & CCT-Adjustable Strips
- 240LED/m/5mm/12W/m — 3CCT Tunable (1 LED WH + 1 LED WW)
- 280LED/m/5mm/12W/m — 3CCT Tunable (1 LED WH + 1 LED WW)
- 192LED/m/8mm/18W/m — 3CCT Tunable (1 LED WH + 1 LED WW)
- 120LED/m/8mm/12W/m — 3CCT Tunable
- 240LED/m/10mm/20W/m — 3CCT Tunable (1 LED WH + 1 LED WW)
- 240LED/m/10mm/15W/m — 2200K-4000K CCT
2. RGB Colour-Changing Strips
- 120LED/m/5mm/16.8W/m — RGB
- 120LED/m/8mm/18W/m — RGB
- 144LED/m/10mm/20W/m — RGB
- 60LED/m/10mm/12W/m — RGB
- 120LED/m/10mm/15W/m — RGB
3. RGB+CCT & Multi-in-1 Strips
- 216LED/m/10mm/20W/m — RGB+CCT
- 60LED/m/12mm/18W/m — RGB+WW 4-in-1
- 120LED/m/12mm/12W/m — RGB+WW 4-in-1
- 60LED/m/12mm/18W/m — RGB+WH 4-in-1
- 60LED/m/12mm/18W/m — RGB+CCT 5-in-1
- 96LED/m/12mm/24W/m — RGB+CCT 5-in-1
4-in-1 and 5-in-1 strips combine RGB colour-changing with white CCT channels on one strip, controlled by a compatible RGB/RGBW controller.
4. IC Running / Addressable-Style Strips
- 60LED/m/10mm/18W/m — RGB+WW
- 72LED/m/10mm/12W/m — RGB
- 120LED/m/10mm/12W/m — WW-NW
- 120LED/m/10mm/12W/m — WH-WW CCT Tunable
IC-driven strips (TM1814 / IC2811 / IC2132 chipsets) for smoother colour transitions and running effects with a compatible IC controller.
Technical Specifications
View complete specification table
| Chip | LED/m | PCB Size | Watt/m | CRI | IP Rating | LED Colour / System | Roll Length |
|---|---|---|---|---|---|---|---|
| 2025 | 240 | 5mm | 12W/m | — | IP20 | 3CCT Tunable (1 LED WH + 1 LED WW) | 10m Roll |
| 2835 | 280 | 5mm | 12W/m | — | IP20 | 3CCT Tunable (1 LED WH + 1 LED WW) | 5m Roll |
| 2835 | 192 | 8mm | 18W/m | — | IP20 | 3CCT Tunable (1 LED WH + 1 LED WW) | 5m Roll |
| 2835 | 120 | 8mm | 12W/m | — | IP20 | 3CCT Tunable | 5m Roll |
| 2835 | 240 | 10mm | 20W/m | — | IP20 | 3CCT Tunable (1 LED WH + 1 LED WW) | 5m Roll |
| 2835 | 240 | 10mm | 15W/m | — | IP20 | 2200K-4000K CCT | 5m Roll |
| 2835 | 120 | 5mm | 16.8W/m | — | IP20 | RGB | 5m Roll |
| 3535 | 120 | 8mm | 18W/m | — | IP20 | RGB | 5m Roll |
| 3535 | 144 | 10mm | 20W/m | — | IP20 | RGB | 5m Roll |
| 5050 | 60 | 10mm | 12W/m | — | IP20 | RGB | 5m Roll |
| 5050 | 120 | 10mm | 15W/m | — | IP20 | RGB | 5m Roll |
| 3535 | 216 | 10mm | 20W/m | — | IP20 | RGB+CCT | 5m Roll |
| 5050 | 60 | 12mm | 18W/m | — | IP20 | RGB+WW 4-in-1 | 5m Roll |
| 5050 | 120 | 12mm | 12W/m | — | IP20 | RGB+WW 4-in-1 | 5m Roll |
| 5050 | 60 | 12mm | 18W/m | — | IP20 | RGB+WH 4-in-1 | 5m Roll |
| 5050 | 60 | 12mm | 18W/m | — | IP20 | RGB+CCT 5-in-1 | 5m Roll |
| 5050 | 96 | 12mm | 24W/m | — | IP20 | RGB+CCT 5-in-1 | 5m Roll |
| 5050 | 60 | 10mm | 18W/m | — | IP20 | RGB+WW | 5m Roll (IC TM1814) |
| 5050 | 72 | 10mm | 12W/m | — | IP20 | RGB | 5m Roll (IC 2811) |
| 2835 | 120 | 10mm | 12W/m | — | IP20 | WW-NW | 5m Roll (IC 2811) |
| 2835 | 120 | 10mm | 12W/m | — | IP20 | WH-WW CCT Tunable | 5m Roll (IC 2132) |
How to Order
Selected LED Strip Specification
Understand the Specification Cards
- 2835 (LED Type)
- the type of LED chip used on the strip.
- LED/m (LED Density)
- number of individual LEDs per running metre; higher density = brighter, more even light.
- PCB Width
- the physical width of the flexible circuit board strip.
- Wattage per Metre
- how much power the strip draws per metre of length; this is what determines driver sizing.
- IP Rating
- the strip's protection level against moisture and dust (IP20 = dry indoor only; IP65 = splash-protected).
- Roll Length
- total metres supplied in one roll.
How to Order Steps
- Identify where the strip will be installed and the light effect you need.
- Choose the LED density and wattage suitable for the application.
- Choose the required CCT or LED colour.
- Confirm the IP rating for the installation area.
- Confirm the number of rolls and size a compatible driver below.
Driver-Selection Calculator
Connected Load: —
Minimum Driver Capacity (after 20% headroom): —
Recommended Driver: —
Shop a Compatible Driver
Choose a constant-voltage driver that matches the LED strip voltage and meets or exceeds the recommended wattage.
Shop Drivers ↗View All LED Drivers
Confirm the output voltage, wattage, IP rating and dimming requirements before purchasing the driver.
Quick Driver Chart — Dry Indoor Use
| Wattage per metre | 5m | 10m | 20m |
|---|
Waterproof Driver-Selection Chart — IP65/Waterproof Installations
| Wattage per metre | 5m | 10m | 20m |
|---|
Need Help Choosing?
Not sure which colour system or controller you need? We offer free guidance on strip and controller selection plus 24V driver sizing.
- WhatsApp: Click here to chat with our lighting expert
- Call: +91-9899188821
Full Price List (PDF)
Download the complete JS-LYT 12V & 24V LED Strip Lights price list — all densities, LED colours and IP ratings in one document.
| Specification | Details |
|---|---|
| Cri | 80< |
| Input voltage | 24V |
| Ip rating | IP20 |
| Led colour temperature | 3CCT Tunable, 2200K-4000K CCT, RGB, RGB+CCT, RGB+WW, RGB+WH, WH-WW CCT Tunable |
| Length | 5m, 10m |
| Product family | JS-LYT |
| Type of item | 24V RGB, CCT & Smart LED Strips |
| Warranty | 2 Years |
| Wattage | 12W, 15W, 16.8W, 18W, 20W, 24W |
