JS-LYT BS Series Waterproof LED Driver 12V/24V 30W-200W – IP67 Mini Constant Voltage Power Supply

Rs. 860.44 - Rs. 2,714.54
Tax included. Shipping charged as per actual — confirmed before dispatch.
Voltage: 12V
Wattage: 30W
Rs. 860.44
Rs. 4,051.05 Rs. 860.44
-79%
In Stock — Ready to ShipOrder today and we dispatch within 2 business days. Ships from · Mumbai
Shipping details

YSD “BS” Mini Series Waterproof LED Power Supply – IP67 — 12V/24V, 30W-200W, IP67
Rs. 860.44
Rs. 4,051.05 Rs. 860.44

YSD “BS” Mini Series Waterproof LED Power Supply – IP67

YSD “BS” Mini Series Waterproof LED Power Supply – IP67 — IP67 rated, 12V/24V constant-voltage LED power supply, available from 30W to 200W.

YSD “BS” Mini Series Waterproof LED Power Supply – IP67

Key features

  • Cooling by free air, high reliability
  • IP67 design for indoor or outdoor installation
  • Can be used in dry, wet and rainy environments
  • Widely used in LED lighting and IT equipment

Available voltage and wattage combinations

Voltage: 12V, 24V
Wattage: 30W, 60W, 100W, 150W, 200W

Amperage table

Voltage Wattage Amperage
12V 30W 2.5A
12V 60W 5A
12V 100W 8.5A
12V 150W 12.5A
12V 200W 17A
24V 30W 1.3A
24V 60W 2.5A
24V 100W 4.2A
24V 150W 6.3A
24V 200W 8.3A

Dimensions (L x W x H)

Voltage Wattage Dimensions
12V 30W 100x27x22mm
12V 60W 120x27x22mm
12V 100W 131x27x22mm
12V 150W 210x29x23mm
12V 200W 210x29x23mm
24V 30W 100x27x22mm
24V 60W 120x27x22mm
24V 100W 131x27x22mm
24V 150W 210x29x23mm
24V 200W 210x29x23mm

IP rating and installation environment

IP67 — suitable for indoor or outdoor installation, subject to correct installation.

Protection features

Short circuit, Overload, Over-voltage, Over-temperature

Suitable applications

LED lighting, IT equipment

Warranty & GST

  • GST: 18% extra
  • Warranty: 2 years
  • No warranty for human damage, wrong wiring, overload use, or environmental factors

Selection & installation guidance

  • Choose a driver wattage at least 20% above your connected LED load for reliable long-term operation.
  • Match the driver voltage (12V / 24V / 48V) to your LED strip or fixture's rated voltage — do not mix voltages.
  • Electrical installation should be completed by a qualified professional.
Specification Details
Body material Metal (compact sealed housing)
Input voltage 12V, 24V
Ip rating IP67
Product family JS-LYT
Shape Linear
Type of item Constant Voltage Driver
Warranty 2 Years
Wattage 30W, 60W, 100W, 150W, 200W
