JS-LYT 24V Flexible Wall Grazer – Indoor IP20

Rs. 3,504.60 - Rs. 10,089.00
Tax included. Shipping charged as per actual — confirmed before dispatch.
Specification: 3030 | 48LED/m | 12mm PCB | 18W/m | IP20 | 10m Roll (with LENSE)
LED Colour: 4000K Neutral White
Rs. 7,965.00
Rs. 37,500.00 Rs. 7,965.00
-79%
Team Will Confirm StockOur team will verify availability and confirm before processing your order.
How it works

JS-LYT 24V Wall Grazer 48 LED IP20 - close-up on reel
Rs. 7,965.00
Rs. 37,500.00 Rs. 7,965.00

JS-LYT 24V Flexible Wall Grazer – Indoor IP20 – 2-Year Warranty

Wide-angle wall-wash 24V strips with a diffusing lens for even, glare-free grazing light on indoor walls and ceilings. Backed by a 2-year manufacturer warranty.

Product Range

1. Flexible Wall Grazer (Indoor)
  • 48LED/m/12mm/18W/m/IP20 — 4000K Neutral White, 3000K Warm White
  • 48LED/m/11mm/25W/m/IP20 — 2700K Extra Warm White
  • 36LED/m/20mm/15W/m/IP20 — RGB+WW

Technical Specifications

View complete specification table
Chip LED/m PCB Size Watt/m CRI IP Rating LED Colour Options Roll Length
3030 48 12mm 18W/m — IP20 4000K Neutral White, 3000K Warm White 10m Roll (with LENSE)
2835 48 11mm 25W/m — IP20 2700K Extra Warm White 10m Roll (CURTAIN GLAZER - 180° - with LENSE)
3030 36 20mm 15W/m — IP20 RGB+WW 5m Roll (CURTAIN GLAZER - with LENSE)
How to Order

Selected LED Strip Specification

Understand the Specification Cards

2835 (LED Type)
the type of LED chip used on the strip.
LED/m (LED Density)
number of individual LEDs per running metre; higher density = brighter, more even light.
PCB Width
the physical width of the flexible circuit board strip.
Wattage per Metre
how much power the strip draws per metre of length; this is what determines driver sizing.
IP Rating
the strip's protection level against moisture and dust (IP20 = dry indoor only; IP65 = splash-protected).
Roll Length
total metres supplied in one roll.

How to Order Steps

  1. Identify where the strip will be installed and the light effect you need.
  2. Choose the LED density and wattage suitable for the application.
  3. Choose the required CCT or LED colour.
  4. Confirm the IP rating for the installation area.
  5. Confirm the number of rolls and size a compatible driver below.

Driver-Selection Calculator

Connected Load: —

Minimum Driver Capacity (after 20% headroom): —

Recommended Driver: —

Shop a Compatible Driver

Choose a constant-voltage driver that matches the LED strip voltage and meets or exceeds the recommended wattage.

Shop Drivers ↗
View All LED Drivers

Confirm the output voltage, wattage, IP rating and dimming requirements before purchasing the driver.

Quick Driver Chart — Dry Indoor Use

Recommended indoor constant-voltage driver sizes
Wattage per metre 5m 10m 20m

Waterproof Driver-Selection Chart — IP65/Waterproof Installations

Recommended waterproof constant-voltage driver sizes
Wattage per metre 5m 10m 20m

Need Help Choosing?

Not sure which spec fits your project? We offer free guidance on strip selection and 24V driver sizing.

Full Price List (PDF)

Download the complete JS-LYT 12V & 24V LED Strip Lights price list — all densities, LED colours and IP ratings in one document.

📖 Download Full Price List (PDF)

Specification Details
Input voltage 24V
Product family JS-LYT
Type of item 24V Flexible Wall Grazer (Indoor)
Warranty 2 Years
